6-inch Non-Torsion Drop Suspension Lift Kit 27220A

video

video
video gallery

6-inch Non-Torsion Drop Suspension Lift Kit 27220A

$1,149.95

Description
Specifications

Description

Weve raised the bar on our 6 in. NTD suspension for 99 - 06 Chevy/GMC 1500 pickups! Gain greater clearance, better handling, and the cleanest looking 6- in. lift available! This kit features set of lifted front knuckles and 6.25in rear fabricated, anti-wrap blocks allow your 1500 to run up to 35in tires. while a full set of high clearance drop crossmembers, differential drop brackets and non torsion bar drop brackets keep everything tucked, hidden, and at optimum angles. Rough Countrys 6 in. NTD Suspension Kit features (4) Premium N3 Nitrogen-charged shocks, giving your truck incredible ride-quality both on and off-road. Also included are a set of front CV spacers, sway-bar links, and a protective skid plate to give you everything you need to get rolling in one of our best kits, now at our best price ever! This all-inclusive kit comes with everything you need, and best of all this kit features Rough Countrys Lifetime Replacement Warranty.

Maintains Factory Ride Quality
Axles Maintain Factory Position And Angle
No Drivetrain Or Exhaust Modifications Req.
Designed To Reuse Factory Compression Travel Stop
Specially Designed Anti-Axle Wrap Rear Blocks
Maintain Stock Ride Quality
While Eliminating Common Lift Block Problem
Will Work w/Auto Trac
Unmatched Ground Clearance
Torsion Bars Stay In Factory Location
Newly Redesigned
Easier Installation

Specifications

SKU:

DHTP-27220A

UPC:

00843030124199

Minimum Purchase:

1 unit

Series:

Suspension Lift Kits

Install Time:

8 - 10 hours

Subcategory:

Lift Kits

California Proposition 65:

Category:

Suspension

Rear Kit Components:

6.25in Fabricated Lift Blocks, U-Bolts, Hardware

Tire, Wheel, And Offset Info:

Trimming Required; 33x12.50R20:20x10:6x5.5:-25; 305 55R20:20x10:6x5.5:-25; 295 65R20:20x10:6x5.5:-25:Minor Trimming; 295 60R20:20x10:6x5.5:-25; 285 60R20:20x10:6x5.5:-25:Minor Trimming; 275 65R20:20x10:6x5.5:-25; 35x12.50R20:20x10:6x5.5:-24:Trimming

Lift/drop Height:

6 in.

Title:

6 Inch Lift Kit - Chevy Silverado & GMC Sierra 1500 4WD (1999-2006 & Classic)

Front Components:

Lifted knuckles, Front crossmember, Rear crossmember, Non-torsion bar drop brackets, Differential drop brackets, Sway-bar links, CV spacers, Skid plate, Hardware

Front Kit Components:

Lifted knuckles, Front crossmember, Rear crossmember, Non-torsion bar drop brackets, Differential drop brackets, Sway-bar links, CV spacers, Skid plate, Hardware

Tire & Wheel Size Combinations:

315/55 R20 - 20x9, Backspacing/Offset: 5in/0mm (If using wheels with -12mm Offset or 4.5-inch Backspacing, some minor inner fender trimming will be required)

Rear Components:

6.25in fabricated lift blocks, U-bolts, Hardware

Tire, Wheel, And Offset Info:

315 75R16:16x8:6x5.5:-6; 305 70R17:17x8.5:6x5.5:-12; 285 75R17:17x8.5:6x5.5:-12; 35x12.50R17:17x8.5:6x5.5:+0; 285 75R17:17x8.5:6x5.5:+0; 35x12.50R17:17x8.5:6x5.5:+1; 35x12.50R17:17x9:6x5.5:-12; 33x12.50R17:17x9:6x5.5:-12; 285 75R17:17x9:6x5.5:-12; 35

Front Kit Componenets:

Lifted knuckles, Front crossmember, Rear crossmember, Non-torsion bar drop brackets, Differential drop brackets, Sway-bar links, CV spacers, Skid plate, Hardware
