4.75-inch Suspension & Body Lift Combo Kit 257.20

(No reviews yet) Write a Review
4.75-inch Suspension & Body Lift Combo Kit 257.20

4.75-inch Suspension & Body Lift Combo Kit 257.20

$649.95

Why Buy Leonard?

This 4.75 in. combo kit features our Nitrogen charged N3 Shocks offer the best in balanced performance for on and off-road use, featuring a 10-stage velocity sensitive valving custom tuned for this specific application. That means these shocks are specifically valved for use with this specific vehicle and lift combo, giving you unparalleled performance for any driving situation.This kit also features upgraded ball joints that are easy to install and maintenance free. These POM ball joints offer a greater range of motion for more wheel articulation than standard or OE replacements and feature a Polyoxymethylene ball race with an extremely low coefficient of friction for longer life, and a larger ball diameter to improve range of motion with a maintenance free design.Also included in this kit are a set of fabricated rear blocks. Fabricated blocks are stronger and offer a longer lifespan than cast blocks while being less susceptible to damage and the environment.

  • Easy Bolt-On Installation
  • Body Lift Raises 1.25 in. As Opposed To The Standard 1 in.
  • Body Lift Includes Front Bumper Brackets
  • Maintains Factory Ride Quality
  • Increased Ground Clearance
  • Able To Be Returned To Stock
  • Levels The Front w/The Rear Of The Vehicle
  • No Need To Disassemble Your Struts To Install
  • Incl. Application Valved N3 Series Shock Absorbers
  • Offer The Best In Balanced Performance For On And Off-road Use
SKU:
DHTP-257.20
UPC:
00843030128388
Minimum Purchase:
1 unit
Lift/drop Height:
4.75 in.
Rear Kit Components:
3in Fabricated Lift Blocks, U-Bolts, Hardware
Install Time:
6 - 8 hours
Title:
4.75 Inch Lift Kit - Combo - Chevy GMC 1500 (07-13)
Category:
Suspension
Tire, Wheel, And Offset Info:
305/70R17:Factory 17:6x5.5; 305/65R18:Factory 18:6x5.5; 305/55R20:Factory 20:6x5.5; 33x12.50R17:17x8.5:6x5.5:+0; 295/70R17:17x8.5:6x5.5:+0; 285/70R17:17x8.5:6x5.5:+0; 33x12.50R17:17x8.5:6x5.5:+1; 295/70R17:17x8.5:6x5.5:+1; 33x12.50R17:17x9:6x5.5:-12;
Subcategory:
Lift Kits
California Proposition 65:
No
Front Kit Componenets:
Upper strut spacers, Upper control arms, Upper ball joints, Differential drops, Differential skid plate, Hardware
Rear Components:
3in fabricated lift blocks, U-bolts, Hardware
Tire & Wheel Size Combinations:
295/55 R20 - 20x9, Offset: 0 to +18mm
Series:
Suspension Lift Kits
Tire, Wheel, And Offset Info:
Trimming Required; 305/55R20:20x10:6x5.5:-25:Minor Trimming; 285/55R20:20x10:6x5.5:-25; 33x12.50R20:20x10:6x5.5:-24:Trimming Required; 305/55R20:20x10:6x5.5:-24:Minor Trimming; 285/55R20:20x10:6x5.5:-24; 33x12.50R20:20x10:6x5.5:-19:Trimming Required;
Front Components:
Upper strut spacers, Upper control arms, Upper ball joints, Differential drops, Differential skid plate, Hardware
allowed_types:
accessories
